Lenovo ThinkCentre M70q Gen 5 Tiny (Intel)

Call 519-483-3560 for pricing and specific model information

  • Up to 14th Gen Intel® Core™ i7-14700T
  • Up to Windows® 11 Pro
  • Up to Intel® UHD graphics 770 (integrated)
  • Up to 64GB DDR5, two SO-DIMMs
  • Up to two drives, 2x M.2 SSD
Category: Brand:

Features

Power Up Your Productivity

Though tiny in form, the ThinkCentre M70q Gen 5 PC boasts powerful performance with up to Intel vPro® Enterprise technology. Intel® Core™ processors, combined with dual-channel memory deliver speedy responsiveness — so you can handle demanding workloads. Plus with flexible expansion slots, this compact device easily accommodates your growing business.

Rear view of Lenovo ThinkCentre Tiny-in-One monitor with Lenovo ThinkCentre M70q Gen 5 Tiny PC attached to the back.
Lenovo ThinkCentre M70q Gen 5 tiny PC, vertically positioned at the right side of the display.

Keep Your Business Your Own

ThinkShield, our suite of security solutions safeguards your critical data and device. A self-healing BIOS restores your system to an earlier state should it ever be corrupted, while discrete Trusted Platform Module encrypts data. Optional Intel vPro® Enterprise boasts multilayered protection against cyber threats, data theft, and more.

Effortless Management

The ThinkCentre M70q Gen 5 Tiny PC boasts hassle-free deployment, upgrades, and management thanks to built-in driver support for older operating system (OS) versions. Tool-less access makes maintenance and expansion to memory modules and storage fast and efficient.

Two ThinkCentre M70 Gen 5 Tiny place one to each other on a white background.
A Lenovo Monitor facing front, with a keyboard, mouse and a ThinkCentre M70q mounted to the back of the monitor. All in a white background.

Tuck it Away or Showcase on a Desk

Looking for a sleek desktop that fits anywhere? The ThinkCentre M70q Gen 5 Tiny can be easily mounted to the back of a monitor, beneath a desk, or even tucked away on a bookshelf (mounting kits sold separately). Plus you can position it horizontally or vertically — whatever suits your needs. What’s more, it supports up to three displays for when you really need to see what’s going on.

ThinkCentre Tough

We use the US Department of Defense’s MIL-STD 810H to create a balance of reliability and durability for our devices. Meeting 12 standards and 17 procedures, ThinkCentre PCs are engineered to run in harsh conditions like the Arctic wilderness, desert dust storms, extreme temps, pressure, humidity, vibration, and more.

Vertically positioned Lenovo ThinkCentre M70q Gen 5 Tiny PC placed at the right side of two forward-facing Lenovo ThinkCentre Tiny-in-One monitor with cables and keyboard & mouse.
A half view of right facing Lenovo ThinkCentre Tiny-in-One monitor with vertically positioned Lenovo ThinkCentre M70q Gen 5 Tiny PC placed at the left side.

Commitment to Recycling

The ThinkCentre M70q Gen 5 tiny PC uses 85% post-consumer content (PCC) recycled acrylonitrile butadiene styrene (ABS) in the chassis. The packaging has 30% ocean-bound plastic in the thermal shell and bag, with a Forest Stewardship Council® (FSC) certified carton. Plus it’s certified ENERGY STAR® 8.0 for energy efficiency and reduced costs.

Ports & Slots

  1. Headphone / mic combo
  2. 2 x USB-A (USB 10Gbps)
  3. USB-C® (USB 5Gbps)
  4. Power button
  5. Kensington Security Slot™
  6. Optional: Expansion slots
  7. Power-in
  8. DisplayPort 1.4
  9. USB-A (USB 5Gbps)
  10. HDMI 2.1 (supports resolutions up to 4K@60Hz)
  11. USB-A (hi-speed USB)
  12. 2 x USB-A (USB 10Gbps)
  13. LAN (1GB)

Processor / Processor Type

13th / 14th Generation Intel® Core i3 / i5 / i7 Processor, or Intel® 300T Processor
Processor / Processor

Core i3-14100T, 4 (4 P-core + 0 E-core), 8 Threads, P-core 2.7GHz, P-core 4.4GHz, 12MB Cache, Intel® UHD Graphics 730
Core i5-14400T, 10 (6 P-core + 4 E-core), 16 Threads, P-core 1.5GHz / E-core 1.1GHz, P-core 4.5GHz / E-core 3.2GHz, 20MB Cache, Intel® UHD Graphics 730
Core i5-14500T, 14 (6 P-core + 8 E-core), 20 Threads, P-core 1.7GHz / E-core 1.2GHz, P-core 4.8GHz / E-core 3.4GHz, 24MB Cache, Intel® UHD Graphics 770
Core i7-14700T, 20 (8 P-core + 12 E-core), 28 Threads, P-core 1.3GHz / E-core 0.9GHz, Max Turbo up to 5.2GHz / P-core 5.0GHz / E-core 3.7GHz, 33MB Cache, Intel® UHD Graphics 770
Operating System / Operating System

Windows® 11 Pro
Graphics / Graphics

Intel® UHD graphics 730, Integrated, Shared, 4096×2160@60Hz(HDMI®), 1x HDMI® 2.1 TMDS, 1x DP 1.4a (HBR2, DSC), 2x optional punch out ports, DirectX® 12
Intel® UHD graphics 770, Integrated, Shared, 4096×2160@60Hz(HDMI®), 1x HDMI® 2.1 TMDS, 1x DP 1.4a (HBR2, DSC), 2x optional punch out ports, DirectX® 12
Monitor Support / Monitor Support

Supports up to 4 independent displays via (onboard DP, onboard HDMI®, 2x optional punch out port)
Chipset / Chipset

Intel® Q670 chipset
Memory / Max Memory

Up to 64GB (2x 32GB DDR5 SO-DIMM)
Memory / Memory Slots

Two DDR5 SO-DIMM slots, dual-channel capable
Memory / Memory Type

DDR5-4800
DDR5-5200
DDR5-5600
Storage / Storage Support

Dual SSD mode: up to two drives, 2x M.2 SSD
• M.2 2280 SSD up to 2TB
Storage / Storage Type

M.2 2280 SSD, PCIe® NVMe® PCIe® 4.0 x4, 256GB / 512GB / 1TB, Opal
M.2 2280 SSD, PCIe® NVMe®,PCIe® 4.0 x4 Performance, 512GB / 1TB / 2TB, Opal
Removable Storage / Optical

None
Removable Storage / Card Reader

No card reader
Multimedia / Audio Chip

High Definition (HD) Audio, Realtek® ALC233VB or Conexant CX11771 codec
Multimedia / Speakers

Single speaker
Power Supply / Power Supply

65W, Adapter, 89%, Autosensing
90W, Adapter, 89%, Autosensing
135W, Adapter, 89%, Autosensing
Input Device / Keyboard

Lenovo® Traditional Keyboard (USB connector), black
Input Device / Mouse

Lenovo® Calliope Mouse (USB connector), black
Mechanical / Form Factor

Tiny (1L)
Mechanical / Dimensions (WxDxH)

179 x 182.9 x 36.5 mm with rubber feet
Mechanical / Packaging Dimensions (WxDxH)

490 x 128 x 250 mm
Mechanical / Weight

Around 1.25 kg
Mechanical / Colour

Black
Mechanical / Expansion Slots

Three M.2 slots (one for WLAN, two for SSD)
Mechanical / Stand

Vertical stand
Connectivity / Ethernet

Gigabit Ethernet, Intel® Ethernet Connection I219-LM, 1x RJ-45, supports Wake-on-LAN
Connectivity / WLAN + Bluetooth

Intel® Wi-Fi® 6E AX211, 802.11ax 2×2 Wi-Fi® + Bluetooth® 5.3, Intel® vPro® technology support, M.2 Card
Ports / Front Ports

1x USB-C® (USB 5Gbps / USB 3.2 Gen 1), with 5V@0.9A charging
1x USB-A (USB 10Gbps / USB 3.2 Gen 2), with Always On and 5V@2.1A charging
1x USB-A (USB 10Gbps / USB 3.2 Gen 2)
1x headphone / microphone combo jack (3.5mm)
Ports / Rear Ports

1x USB-A (Hi-Speed USB / USB 2.0)
1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
2x USB-A (USB 10Gbps / USB 3.2 Gen 2)
1x HDMI® 2.1 TMDS
1x DisplayPort™ 1.4a (HBR2, DSC)
1x Ethernet (RJ-45)
Security / Security Chip

Discrete TPM 2.0, TCG certified
Security / Physical Locks

Kensington® Security Slot, 3 x 7 mm
Security / BIOS Security

Administrator password
Hard disk password
Power-on password
Boot sequence control
Certificate based BIOS authentication
Cover presence switch
Individual USB port disablement
Secure Boot
Secure Wipe
Self-healing BIOS
Smart USB protection (allows keyboard / mouse only, blocks all storage devices)
System Management / System Management

Intel® vPro® Enterprise
Non-vPro®
Warranty / Base Warranty

3-year limited onsite service
