Lenovo ThinkCentre M90s Gen 5 (Intel) Small Form Factor

Call 519-483-3560 for pricing and specific model information

  • Up to 14th Gen Intel® Core™ i9-14900
  • Up to Windows® 11 Pro
  • Up to Intel® Arc™ A310 LP
  • 4GB Up to 128GB DDR5, four DIMMs
  • Support up to four drives, 1x 3.5″ HDD + 1x open 2.5″ HDD bay + 2x M.2 SSD
Category: Brand:

Features

Peak Processing Performance

No program is too intricate, and no file is too massive to hinder the Lenovo ThinkCentre M90s Gen 5 (Intel) SFF from operating at the speed of human imagination. With cutting-edge Intel vPro® Enterprise technology and Intel® Core™ processors, this desktop delivers real-world, top-notch performance for business needs.

A person sits at a desk working on a Lenovo ThinkCentre M90s Gen 5 small form factor PC in the foreground & a curved Lenovo ThinkVision monitor, keyboard & mouse.
A doctor sits at a desk with the Lenovo ThinkCentre M90s Gen 5 small form factor PC in the foreground & a monitor with a video conference taking place.

Confidently Secured

Lenovo ThinkShield offers thorough security, combining hardware and software to protect your data. The discrete Trusted Platform Module (dTPM) chip encrypts passwords and data, while BIOS-based Smart USB Protection prevents unauthorized access through peripherals. Leveraging the Intel vPro® platform, this device enhances data and asset security.

Expandable Flexibility

The ThinkCentre M90s Gen 5 (Intel) Small Form Factor has a host of slots and ports to connect to multiple peripherals. Moreover, it’s easy to deploy from both a software and hardware standpoint.

A person with a headset on sits in front of four monitors reviewing graphs & charts, with the Lenovo ThinkCentre M90s Gen 5 small form factor PC in the foreground.
A person at a desk with two Lenovo ThinkVision monitors & the Lenovo ThinkCentre M90s Gen 5 in the foreground.

Environmentally Aware

This small form factor desktop was crafted with a strong emphasis on recycling. Our commitment to sustainability is evident in the integration of recycled post-consumer content (PCC) into various components. The packaging is thoughtfully designed using a combination of recycled and sustainably sourced materials.

Ports & Slots

Two Lenovo ThinkCentre M90s Gen 5 small form factor PCs, one front-facing with ports & slots labeled 1-8 & one rear-facing with ports & slots labeled 9-19.
  1. Optional: Slim ODD
  2. Optional: card reader 3-in-1
  3. USB-C® (USB 10Gbps, 15W charging)
  4. 2 x USB-A (USB 5Gbps)
  5. 2 x USB-A (USB 10Gbps)
  6. Power button
  7. Microphone
  8. Headphone / mic combo
  9. Audio-out
  10. Optional: Flex IO
  11. HDMI® 2.1 (supports resolution up to 4K@60Hz)
  12. DisplayPort 1.4
  13. 4 x USB-A (USB 5Gbps)
  14. Kensington Security Slot™
  15. DisplayPort 1.4
  16. Optional: 2 x PS/2 ports (keyboard / mouse)
  17. Ethernet (RJ45)
  18. Optional: Slots on expansion cards
  19. Power-in

Processor / Processor Type

13th Generation Intel® Core i5 / i7 or 14th Generation Intel® Core i5 / i7 / i9 Processor
Processor / Processor

Core i5-14500, 14 (6 P-core + 8 E-core), 20 Threads, P-core 2.6GHz / E-core 1.9GHz, P-core 5.0GHz / E-core 3.7GHz, 24MB Cache, Intel® UHD Graphics 770
Core i7-14700, 20 (8 P-core + 12 E-core), 28 Threads, P-core 2.1GHz / E-core 1.5GHz, Max Turbo up to 5.4GHz / P-core 5.3GHz / E-core 4.2GHz, 33MB Cache, Intel® UHD Graphics 770
Core i9-14900 24 (8 P-core + 16 E-core), 32 Threads, P-core 2.0GHz / E-core 1.5GHz, Max Turbo up to 5.8GHz / P-core 5.4GHz / E-core 4.3GHz, 36MB Cache, Intel® UHD Graphics 770
Operating System / Operating System

Windows® 11 Pro
Graphics / Graphics

Intel® UHD graphics 770, Integrated, Shared, 4096×2304@60Hz(DP) / 4096×2160@60Hz[HDMI®, 2x DP 1.4a (HBR2, DSC), 1x HDMI® 2.1 TMDS, 1x Flex IO (VGA / DP 1.2 / HDMI® 2.1 TMDS / USB-C®), DirectX® 12
Intel® Arc™ A310 LP Graphics, Discrete, 4GB GDDR6, 5120×2880@60Hz(DP), 2x DisplayPort™ 1.4a, DirectX® 12, OpenGL 4.6
Monitor Support / Monitor Support

upports up to 4 independent displays via onboard ports (2x DP, 1x HDMI®, and 1x optional Flex IO), more displays support via discrete graphics
Chipset / Chipset

Intel® Q670 chipset
Memory / Max Memory

Up to 128GB DDR5
Memory / Memory Slots

Four DDR5 UDIMM slots, dual-channel capable
Memory / Memory Type

DDR5-3600
DDR5-4000
DDR5-4400
Storage / Storage Support

Up to four drives, 1x 3.5" HDD + 1x 2.5" HDD + 2x M.2 SSD
• 3.5" HDD up to 2TB
• 2.5" HDD bay is only for customer self upgrade
• M.2 SSD up to 2TB each
Storage / Storage Type

3.5" SATA HDD, SATA 6Gb/s, 7.2K, –
M.2 2280 SSD, PCIe® NVMe® PCIe® 4.0 x4, -, Opal 2.0
Removable Storage / Optical

DVD burner (DVD±RW), SATA connector, slim (9.0mm)
Removable Storage / Card Reader

No card reader
Multimedia / Audio Chip

High Definition (HD) Audio, Realtek® ALC897Q-CG codec
Multimedia / Speakers

Single speaker, 1W x1
Power Supply / Power Supply

260W, Fixed, 90%, 100-240V, 50-60Hz
310W, Fixed, 92%, 100-240V, 50-60Hz
Input Device / Keyboard

Lenovo® Traditional Keyboard (USB connector), black
Input Device / Mouse

Lenovo® Calliope Mouse (USB connector), black
Mechanical / Form Factor

SFF (8.2L)
Mechanical / Dimensions (WxDxH)

92.5 x 297.7 x 339.5 mm
Mechanical / Packaging Dimensions (WxDxH)

195 x 395 x 530 mm
Mechanical / Weight

Around 5.3 kg
Mechanical / Packaging Weight

7.6 kg
Mechanical / Colour

Black
Mechanical / Bays

1x 3.5" disk bay
1x slim ODD bay
Mechanical / Expansion Slots

One PCIe® 4.0 x16 (x4 signal), low-profile, length ≤ 155mm, height ≤ 70mm
One PCIe® 4.0 x16, low-profile, length ≤ 155mm, height ≤ 70mm
One PCIe® 3.0 x1, low-profile, length ≤ 155mm, height ≤ 70mm
Three M.2 slots (one for WLAN, two for SSD)
Mechanical / Stand

Vertical stand
Connectivity / Ethernet

Gigabit Ethernet, Intel® Ethernet Connection I219-LM, 1x RJ-45, supports Wake-on-LAN
Connectivity / WLAN + Bluetooth

Intel® Wi-Fi® 6E AX211, 802.11ax 2×2 Wi-Fi® + Bluetooth® 5.3, Intel® vPro® technology support, M.2 Card
Ports / Front Ports

1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with 15W charging
2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
2x USB-A (USB 10Gbps / USB 3.2 Gen 2)
1x headphone / microphone combo jack (3.5mm)
1x microphone (3.5mm)
Ports / Rear Ports

4x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x HDMI® 2.1 TMDS
2x DisplayPort™ 1.4a (HBR2, DSC)
1x Ethernet (RJ-45)
1x line-out (3.5mm)
Security / Security Chip

Discrete TPM 2.0, TCG certified, FIPS 140-2 certified
Security / Physical Locks

Kensington® Security Slot, 3 x 7 mm
Padlock Loop
Security / BIOS Security

Administrator password
Hard disk password
Power-on password
Boot sequence control
Boot without keyboard and mouse
Certificate based BIOS authentication
Individual USB port disablement
Self-healing BIOS (Level 2)
Smart USB protection (allows keyboard / mouse only, blocks all storage devices)
System Management / System Management

Intel® vPro® Enterprise
Warranty / Base Warranty

1-year limited onsite service
3-year limited onsite service
