Lenovo ThinkCentre M90t Gen 5 (Intel) Tower

Call 519-483-3560 for pricing and specific model information

  • Up to 14th Gen Intel® Core™ i9-14900
  • Up to Windows® 11 Pro
  • NVIDIA® GeForce RTX™ 4060 8GB
  • Up to 128GB DDR5, four DIMMs
  • Support up to five drives, 2x 3.5″ HDD + 1x open 2.5″ HDD bay + 2x M.2 SSD
Category: Brand:

Features

AI-powered Performance

Revolutionize every task using Lenovo’s cutting-edge AI-accelerated functions to elevate efficiency. Designed for demanding multitasking and data-intensive tasks, the Lenovo ThinkCentre M90t Gen 5 (Intel) Tower emphasizes power management, delivering the necessary performance enhancements precisely when and where they are needed.

ThinkCentre M90t Gen 5 in the foreground with a young woman working on a PowerPoint presentation displayed on a double monitor.
ThinkCentre M90t Gen 5 shown in the foreground with a man conducting a video conference call.

Focused on Security

Lenovo ThinkShield provides comprehensive security by integrating hardware and software to safeguard your data. Through the discrete Trusted Platform Module (dTPM) chip, passwords and data are encrypted, while BIOS-based Smart USB Protection thwarts unauthorized access via peripherals. By leveraging the Intel vPro® platform, it elevates asset security standards.

Optimal Processing Power

No task is too complex to keep the Lenovo ThinkCentre M90t Gen 5 (Intel) Tower from keeping pace with the speed of business. Equipped with advanced Intel vPro® Enterprise technology and Intel® Core™ processors, this desktop ensures exceptional performance. Elevate every digital assignment with Lenovo’s cutting-edge AI-accelerated functionalities, enhancing overall performance.

ThinkCentre M90t Gen 5 shown with four monitors, a keyboard and mouse, each monitor is displaying a different task.
ThinkCentre M90t Gen 5 shown from the back along with a super wide curved Lenovo monitor.

Enhanced Versatility

The ThinkCentre M90t Gen 5 (Intel) Tower makes multitasking a breeze with multiple ports and expansion slots. Moreover, it’s easy to deploy from both a software and hardware standpoint.

Environmental Sustainability

This workstation is meticulously designed with a strong focus on recycling. Our dedication to sustainability shines through the incorporation of recycled post-consumer content (PCC) in different parts such as the chassis, keyboard, and mouse. The packaging is thoughtfully crafted using a blend of recycled and sustainably sourced materials.

ThinkCentre M90t Gen 5 facing right of the screen along with a super wide Lenovo curved monitor, wireless keyboard, and mouse.

Ports & Slots

Two Lenovo ThinkCentre M90t Gen 5 tower PCs, one front-facing with ports & slots labeled 1-8 & one rear-facing with ports & slots labeled 9-19.
  1. Optional: Slim optical disc drive
  2. Power button
  3. Optional: card reader (3-in-1)
  4. Mic
  5. Headphone / mic combo
  6. USB-C®, (USB 10Gbps)
  7. 2 x USB-A (USB 10Gbps)
  8. 2 x USB-A (USB 5Gbps)
  9. Audio-out
  10. Optional: Flex IO
  11. HDMI® 2.1 (supports resolution up to 4K@60Hz)
  12. 2 x DisplayPort 1.4
  13. 4 x USB-A (USB 5Gbps)
  14. Ethernet (RJ45)
  15. Optional: 2 x PS/2 ports (keyboard / mouse)
  16. Optional: Serial
  17. Optional: Expansion card slots
  18. Kensington Security Slot™
  19. Power-in

Processor / Processor Type

13th Generation Intel® Core i5 / i7 or 14th Generation Intel® Core i5 / i7 / i9 Processor
Processor / Processor

Core i5-14500, 14 (6 P-core + 8 E-core), 20 Threads, P-core 2.6GHz / E-core 1.9GHz, P-core 5.0GHz / E-core 3.7GHz, 24MB Cache, Intel® UHD Graphics 770
Core i7-14700, 20 (8 P-core + 12 E-core), 28 Threads, P-core 2.1GHz / E-core 1.5GHz, Max Turbo up to 5.4GHz / P-core 5.3GHz / E-core 4.2GHz, 33MB Cache, Intel® UHD Graphics 770
Core i9-14900, 24 (8 P-core + 16 E-core), 32 Threads, P-core 2.0GHz / E-core 1.5GHz, Max Turbo up to 5.8GHz / P-core 5.4GHz / E-core 4.3GHz, 36MB Cache, Intel® UHD Graphics 770
Operating System / Operating System

Windows® 11 Pro
Graphics / Graphics

Intel® UHD graphics 730, Integrated, Shared, 4096×2304@60Hz(DP) / 4096×2160@60Hz[HDMI®, 2x DP 1.4a (HBR2, DSC), 1x HDMI® 2.1 TMDS, 1x Flex IO (VGA / DP 1.2 / HDMI® 2.1 TMDS / USB-C®), DirectX® 12
AMD Radeon™ RX 6600 LE, Discrete, 8G GDDR6, 7680×4320@60Hz(HDMI®) / 7680×4320@ 60Hz(DP), 3x DP 1.4a, 1x HDMI® 2.1 FRL, DirectX® 12, OpenGL 4.6, OpenCL 2.2
NVIDIA® GeForce RTX 4060, Discrete, 8G GDDR6, 7680×4320@60Hz(HDMI®) / 7680×4320@60Hz(DP), 1x HDMI® 2.1a FRL, 3x DP 1.4a, DirectX® 12, OpenGL 4.6
Monitor Support / Monitor Support

Supports up to 4 independent displays via onboard ports (2x DP, 1x HDMI®, and 1x optional Flex IO), more displays support via discrete graphics
Chipset / Chipset

Intel® Q670 chipset
Memory / Max Memory

Up to 128GB DDR5
Memory / Memory Slots

Four DDR5 UDIMM slots, dual-channel capable
Memory / Memory Type

DDR5-3600
DDR5-4000
DDR5-4400
Storage / Storage Support

Up to five drives, 2x 3.5" HDD + 1x 2.5" HDD + 2x M.2 SSD
• 3.5" HDD up to 2TB
• 2.5" HDD bay is only for customer self upgrade
• M.2 SSD up to 2TB each
Storage / Storage Type

3.5" SATA HDD, SATA 6Gb/s, 7.2K, –
M.2 2280 SSD, PCIe® NVMe® PCIe® 4.0 x4, -, Opal 2.0
Removable Storage / Optical

DVD burner (DVD±RW), SATA connector, slim (9.0mm)
Removable Storage / Card Reader

No card reader
Multimedia / Audio Chip

High Definition (HD) Audio, Realtek® ALC897Q-CG codec
Multimedia / Speakers

Single speaker, 2W x1
Power Supply / Power Supply

300W, Fixed, 90%, 100-240V, 50-60Hz
500W, Fixed, 92%, 100-240V, 50-60Hz
Input Device / Keyboard

Lenovo® Traditional Keyboard (USB connector), black
Input Device / Mouse

Lenovo® Calliope Mouse (USB connector), black
Mechanical / Form Factor

Tower (17L)
Mechanical / Dimensions (WxDxH)

170 x 298 x 376 mm
Mechanical / Packaging Dimensions (WxDxH)

275 x 395 x 540 mm
Mechanical / Weight

Around 6.5 kg
Mechanical / Packaging Weight

9.8 kg
Mechanical / Colour

Black
Mechanical / Bays

1x 3.5" disk bay
1x 3.5" disk bay (optional, or bay comes with disk)
1x slim ODD bay
Mechanical / Expansion Slots

One PCIe® 4.0 x16 (x4 signal), full-height, length ≤ 205mm, height ≤ 114.55mm
One PCIe® 4.0 x16, full-height, length ≤ 268.5mm, height ≤ 114.55mm
One PCIe® 3.0 x1, full-height, length ≤ 205mm, height ≤ 114.55mm
Three M.2 slots (one for WLAN, two for SSD)
Mechanical / EOU

Toolless cover, memory, disk, optical, extension card assembly / removal
Mechanical / Stand

No stand
Mechanical / Others

Supports Smart Power On
Connectivity / Ethernet

Gigabit Ethernet, Intel® Ethernet Connection I219-LM, 1x RJ-45, supports Wake-on-LAN
Connectivity / WLAN + Bluetooth

Intel® Wi-Fi® 6E AX211, 802.11ax 2×2 Wi-Fi® + Bluetooth® 5.3, Intel® vPro® technology support, M.2 Card
Ports / Front Ports

1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with 15W charging
2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
2x USB-A (USB 10Gbps / USB 3.2 Gen 2)
1x headphone / microphone combo jack (3.5mm)
1x microphone (3.5mm)
Ports / Rear Ports

4x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x HDMI® 2.1 TMDS
2x DisplayPort™ 1.4a (HBR2, DSC)
1x Ethernet (RJ-45)
1x line-out (3.5mm)
Security / Security Chip

Discrete TPM 2.0, TCG certified, FIPS 140-2 certified
Security / Physical Locks

Kensington® Security Slot, 3 x 7 mm
Padlock Loop
Security / BIOS Security

Administrator password
Hard disk password
Power-on password
Boot sequence control
Boot without keyboard and mouse
Certificate based BIOS authentication
Individual USB port disablement
Self-healing BIOS (Level 2)
Smart USB protection (allows keyboard / mouse only, blocks all storage devices)
System Management / System Management

Intel® vPro® Enterprise
Warranty / Base Warranty

1-year limited onsite service
3-year limited onsite service
