ThinkPad P14s Gen 5 (14″ Intel) Mobile Workstation

Call 519-483-3560 for pricing and specific model information

  • Up to Intel® Core™ Ultra 9 185H
  • Up to Windows® 11 Pro
  • Up to NVIDIA® RTX 500 Ada Generation 4GB GDDR6
  • Brand new 14.5″ display, up to 3K 430nits, 100% DCI-P3
  • Standard support for TÜV Low Blue Light, Eyesafe® Certified 2.0
Categories: , Brand:

Features

When You Dare to do More With Raw Power

Unlock AI efficiency for superior computing prowess with the ThinkPad P14s Gen 5 mobile workstation. Driven by Intel® Core™ Ultra processor with an integrated Neural Processing Unit (NPU), this machine ensures peak performance on the go. While Intel vPro® boosts enterprise security, pro-grade NVIDIA® RTX™ graphics simplify heavy workflows.

Beyond the Boundaries of Conventional Viewing

We’ve redefined the visual experience on the P14s Gen 5 workstation. Its 14.5” screen brightens every pixel for precise clarity. Each display option is antiglare treated and certified for low blue light to prevent eye fatigue. Plus, the Communication Bar atop the screen boasts a hi-res 5MP camera and superior mics for consistent audio-video calls.

Close-up, front view of Lenovo ThinkPad P14s Gen 5 (14 inch AMD) black laptop placed on a desk opened 90 degrees, focusing its screen showing a 3D modeling software on the left & a video editing app on the right.
Two people working on some graphics app opened on the Lenovo ThinkPad P14s Gen 5 (14 inch AMD) black touchscreen laptop placed on a desk in a technical lab setting with some other people working in a blur background.

Break Free, Stay Connected — Anywhere, Everywhere

Propel your productivity on the P14s Gen 5 Intel mobile workstation. Its ample ports, swift memory, and uninterrupted connectivity with advanced WiFi capabilities enable you to keep pace with your workflows. Perfect for power users, industrial engineers, and designers, it renders top-tier performance at an economical price.

Customizable, Controllable, Unstoppable

Our ThinkPad keyboard is redesigned for improved accessibility and greater control. Its enlarged TrackPad offers navigation precision, while the TrackPoint Quick Menu optimizes audio-visual settings with just a double tap. That’s not all — its advanced cooling system with dual-fan setup and rear vents guarantee peak thermal performance everywhere.

Performance That Doesn’t Cost the Earth

Designed for reliable operation under heavy workloads, this laptop includes powerful Intel® Arc™ graphics, plus the option of NVIDIA® RTX™ Ada discrete graphics. The P14s Gen 5 workstation boasts a number of independent software vendors (ISV) certified apps like AVID® and Autodesk®. It’s also energy-efficient and holds several environmental certifications. Plus, you’ll love that it’s built in part with recycled plastics and metals. See Tech Specs.

Security at its Finest: Defend, Detect, Deter

ThinkShield, our advanced security suite of hardware and software solutions, safeguards your device with data encryption and biometrics. Additionally, AI-powered Intel® Threat Detection technology helps prevent ransomware, cryptojacking, and more. When it comes to security and protecting your assets, we’ve got you covered!

Tested Tough to Challenge the Extremes

We use the US Department of Defense’s MIL-STD 810H to create a balance of reliability and durability for ThinkPad laptops. Meeting or exceeding 12 standards, 26 procedures, and 200+ quality checks ensure that the ThinkPad P14s Gen 5 (14” Intel) mobile workstation runs in extreme conditions, and withstands life’s trips and spills.

Ports & Slots

Image showing left & right side profiles of Lenovo ThinkPad P14s Gen 5 (14 inch AMD) black laptop opened at 90 degrees with left side ports labeled from 1 to 4 & right side ports labeled form 5 to 9.
  1. HDMI® 2.1 (supports resolution up to 4K@60Hz)
  2. 2 x USB-C® (Thunderbolt™ 4, USB 40Gbps)
  3. USB-A (USB 5Gbps) (always on)
  4. Headphone / mic combo
  5. Smart card reader (optional)
  6. USB-A (USB 5Gbps)
  7. Ethernet (RJ45)
  8. Kensington Nano Security Slot™
Processor / Family

Intel® H Series Core Ultra 5 / 7 / 9 Processor; supports up to 16 cores; up to 5.1GHz; TDP ratings of up to 50W
Processor / Name

Core Ultra 5 125H, 14 (4 P-core + 8 E-core + 2 LPE-core), 18 threads, P-core 1.2GHz / E-core 700MHz / LPE-core 700MHz, P-core 4.5GHz / E-core 3.6GHz / LPE-core 2.5GHz, 18MB Cache, Intel® Arc™ Graphics, Intel® AI Boost
Core Ultra 5 135H, 14 (4 P-core + 8 E-core + 2 LPE-core), 18 threads, P-core 1.7GHz / E-core 1.2GHz / LPE-core 700MHz, P-core 4.6GHz / E-core 3.6GHz / LPE-core 2.5GHz, 18MB Cache, Intel® Arc™ Graphics, Intel® AI Boost
Core Ultra 7 155H, 16 (6 P-core + 8 E-core + 2 LPE-core), 22 threads, P-core 1.4GHz / E-core 900MHz / LPE-core 700MHz, P-core 4.8GHz / E-core 3.8GHz / LPE-core 2.5GHz, 24MB Cache, Intel® Arc™ Graphics, Intel® AI Boost
Core Ultra 7 165H, 16 (6 P-core + 8 E-core + 2 LPE-core), 22 threads, P-core 1.4GHz / E-core 900MHz / LPE-core 700MHz, P-core 5.0GHz / E-core 3.8GHz / LPE-core 2.5GHz, 24MB Cache, Intel® Arc™ Graphics, Intel® AI Boost
Core Ultra 9 185H, 16 (6 P-core + 8 E-core + 2 LPE-core), 22 threads, P-core 2.3GHz / E-core 1.8GHz / LPE-core 1GHz, P-core 5.1GHz / E-core 3.8GHz / LPE-core 2.5GHz , 24MB Cache, Intel® Arc™ Graphics, Intel® AI Boost
AI (Artificial Intelligence) / NPU

Integrated Intel® AI Boost, up to 11 TOPS
Operating System / Name

Windows 11 Pro
Graphics / Name

Intel® Arc™ Graphics, Integrated, Shared, Share CPU TDP, DirectX® 12.2
Intel® Graphics, Integrated, Shared, Share CPU TDP, DirectX® 12.1
NVIDIA® RTX 500 Ada Generation Laptop GPU, Discrete, 4GB GDDR6, 35W, DirectX® 12 Ultimate
Chipset / Type

Intel® SoC (System on Chip) platform
Memory / Max

Up to 96GB (2x 48GB DDR5 SO-DIMM)
Memory / Slots

Two DDR5 SO-DIMM slots, dual-channel capable
Memory / Type

DDR5-5600 non-ECC, maximum transfer speeds of up to 5600 MT/s
Storage / Support

One drive, up to 2TB M.2 2280 SSD
Storage / Slot

One M.2 2280 PCIe® 4.0 x4 slot
Storage / Type

M.2 2280 SSD, PCIe NVMe®, PCIe 4.0 x4 256GB / 512GB / 1TB
M.2 2280 SSD, PCIe NVMe, PCIe 4.0 x4 Performance 512GB / 1TB / 2TB
Removable Storage / Card Reader

No card reader
Multimedia / Audio

High Definition (HD) Audio, Realtek® ALC3287 codec
Multimedia / Speakers

Stereo speakers, 2W x2, Dolby Audio™
Multimedia / Microphone

Dual-microphone array, 360° far-field, Dolby Voice®
Multimedia / Camera

5.0MP + IR with privacy shutter, fixed focus, temporal noise reduction
5.0MP with privacy shutter, fixed focus, temporal noise reduction
Battery / Battery

Integrated Li-Polymer 75Wh battery, supports Rapid Charge (charge up to 80% in 1hr)
Power Adapter / Power Adapter

135W USB-C® slim (3-pin) AC adapter, supports PD 3.0, 100-240V, 50-60Hz
Display / Display

14.5", WUXGA (1920×1200), None, IPS, 300nits, Anti-glare, 16:10, 800:1, 45% NTSC, 60Hz
14.5", 3K (3072×1920), None, IPS, 430nits, Anti-glare, 16:10, 1500:1, 100%, DCI-P3, 120Hz
14.5", WQXGA (2560×1600), None, IPS, 350nits, Anti-glare, 16:10, 1500:1, 100% sRGB, 90Hz
14.5", WQXGA (2560×1600), Add-on Film Touch, IPS, 350nits, Anti-glare, 16:10, 1500:1, 100% sRGB, 90Hz
Display / Colour Calibration

TCON factory color calibration (3K display)
X-Rite® factory color calibration (selected WQXGA display)
No color calibration
Display / Touchscreen

Add-on Film Touch, supports 10-point touch (selected WQXGA display)
Non-touch
Input Device / Keyboard

6-row, spill-resistant, multimedia Fn keys, Copilot key
Input Device / Keyboard Backlight

LED backlight
Input Device / UltraNav

3-button TrackPoint® pointing device and glass-like Mylar® surface multi-touch TrackPad, 60 x 115 mm
Mechanical / Dimensions

325.5 x 227.6 x 18.5 mm
Mechanical / Weight

Starting at 1.61 kg
Mechanical / Case Colour

Black
Mechanical / Case Material

Aluminium (top), aluminium (bottom)
Network / Ethernet

Gigabit Ethernet, Intel® Ethernet Connection I219-LM (vPro® models), 1x RJ-45, supports Wake-on-LAN
Gigabit Ethernet, Intel® Ethernet Connection I219-V (non-vPro® models), 1x RJ-45, supports Wake-on-LAN
Network / WLAN + Bluetooth

Intel® Wi-Fi® 6E AX211, 802.11ax 2×2 Wi-Fi® + Bluetooth® 5.3
Network / WWAN

No support
Network / SIM Card

No physical SIM card inbox
Network / NFC

No support
Ports / Standard Ports

1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 2.1
1x HDMI® 2.1, up to 4K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
1x Security keyhole
Docking / Docking

Various docking solutions supported via Thunderbolt™ or USB-C
Security / Security Chip

Discrete TPM 2.0, TCG certified, FIPS 140-2 certified
Security / Physical Locks

Kensington® Nano Security Slot™, 2.5 x 6 mm
Security / Smart Card Reader

No smart card reader
Security / Fingerprint Reader

Touch style fingerprint reader integrated in power button, match-on-chip
Security / BIOS Security

Supervisor password
Power-on password
NVMe® password
Self-healing BIOS
Security / Other Security

Camera privacy shutter (camera models)
System Management / System Management

Intel® vPro® Enterprise
Non-vPro®
Warranty / Base Warranty

3-year (1-yr battery) courier or carry-in service
