ThinkPad T14 Gen 5 (AMD) Laptop

Call 519-483-3560 for pricing and specific model information

  • AI PC, lightweight performance-focused laptop
  • Up to AMD Ryzen™ 7 PRO 8840U
  • Up to AMD Radeon™ 780M Graphics (integrated)
  • Up to 64GB DDR5-5600, 2x SO-DIMM
  • Up to 1x 2TB M.2 PCIe® NVMe® SSD
  • Up to 14″ 2.8K OLED, 400nits, 100% DCI-P3, Eyesafe®

Features

Unprecedented Productivity Anywhere, Everywhere

Explore amazing computing and power efficiency on the go with the 14″ ThinkPad T14 Gen 5 laptop, fueled by the AMD Ryzen™ PRO processor. Energize your creative work with vivid AMD Radeon™ graphics. Plus, enjoy AI-powered collaboration features like voice focus and automatic framing to boost your productivity and elevate your remote work experience.

A Display That Brightens Your Workday

Bask in the pristine clarity of visuals on the T14 Gen 5 laptop with the 2.8K OLED display option and the 3M optical solutions boost brightness with power-saving luminance. A number of displays feature the choice of low blue-light-certification to prevent eye fatigue and strain. Plus, choose from elegant shades of Eclipse Black and Luna Grey.

More Confidence & Better Control

Our redesigned ThinkPad keyboard includes tactile markings for easy key recognition and an enlarged TrackPad (120mm / 4.72ʺ) for greater control. A double tap on the TrackPoint activates a Quick Menu for customizable settings. And the Communications Bar atop the screen boasts a 5MP camera and noise-canceling mics for a sharper audio-visual focus.

Intuitive Features, Impactful Design

Stay productive all day with the T14 Gen 5 laptop, which seamlessly adapts to your workflow by adjusting battery usage. Its advanced thermal design features a dual-fan system with rear air vents for superior cooling. Plus, it’s durability-tested to MIL-STD-810H specifications and promotes energy efficiency with an ENERGY STAR® 8.0 certification.

Power to You With DIY Ease

The ThinkPad T14 Gen 5 laptop offers long-lasting durability and allows for easy self-repairs with its customer replaceable units (CRU) — requiring no tech expertise. Its remarkable do-it-yourself capabilities are highlighted by a high 9.3/10 rating on the iFixit Repairability Scale to ensure effortless upgrades and component replacements.

State-of-the-art Security Solutions

Enjoy peace of mind with assured data security on the T14 Gen 5 laptop. With ThinkShield, our advanced security suite, your data is encrypted by a discrete Trusted Platform Module (dTPM). Optional biometrics provide extra security, from fingerprint reader to facial recognition login, while a webcam privacy shutter maintains visual privacy when needed.

Ports & Slots

  1. 2 x USB-C® (USB4® 40Gbps)
  2. HDMI® 2.1 (supports resolution up to 4K@60Hz)
  3. USB-A (USB 5Gbps)
  4. Headphone / mic combo
  5. Optional Smart card reader
  6. Optional Nano Sim Slot
  7. USB-A (USB 5Gbps)
  8. Ethernet (RJ45)
  9. Kensington Nano Security Slot™
Processor / Family

AMD Ryzen™ 5 / 7 8000 Series Processor

Processor / Name

AMD Ryzen™ 5 PRO 8540U, 6 Cores, 12 Threads, 3.2GHz, 4.9GHz, 6MB L2 / 16MB L3 Cache, AMD Radeon™ 740M
AMD Ryzen™ 7 PRO 8840U, 8 Cores, 16 Threads, 3.3GHz, 5.1GHz, 8MB L2 / 16MB L3 Cache, AMD Radeon™ 780M, AMD Ryzen™ AI

AI (Artificial Intelligence) / AI PC Category

AI PC

AI (Artificial Intelligence) / NPU

Integrated AMD Ryzen™ AI, up to 16 TOPS

Operating System / Name

Windows 11 Pro

Graphics / Name

AMD Radeon™ 740M, Integrated, Shared, DirectX® 12
AMD Radeon™ 780M, Integrated, Shared, DirectX® 12

Chipset / Type

AMD SoC (System on Chip) platform

Memory / Max

Up to 64GB DDR5-5600

Memory / Slots

Two DDR5 SO-DIMM slots, dual-channel capable

Memory / Type

DDR5-5600

Storage / Support

One drive, up to 2TB M.2 2280 SSD

Storage / Slot

One M.2 2280 PCIe® 4.0 x4 slot

Storage / Type

M.2 2280 SSD, PCIe NVMe®, PCIe 4.0 x4 256GB / 512GB / 1TB
M.2 2280 SSD, PCIe NVMe, PCIe 4.0 x4 Performance 512GB / 1TB / 2TB

Removable Storage / Card Reader

No card reader

Multimedia / Audio

High Definition (HD) Audio, Realtek® ALC3287 codec

Multimedia / Speakers

Stereo speakers, 2W x2, Dolby Audio™

Multimedia / Microphone

Dual-microphone array, 360° far-field, Dolby Voice

Multimedia / Camera

5.0MP + IR discrete, with privacy shutter, fixed focus, temporal noise reduction
5.0MP, with privacy shutter, fixed focus, temporal noise reduction

Battery / Battery

Integrated Li-Polymer 52.5Wh battery, supports Rapid Charge (charge up to 80% in 1hr) with 65W AC adapter

Power Adapter / Power Adapter

65W USB-C® (2-pin) AC adapter, supports PD 3.0, 100-240V, 50-60Hz

Display / Display

14", WUXGA (1920×1200), None, IPS, 400nits, Anti-glare, 16:10, 1000:1, 45% NTSC, 60Hz
14", WUXGA (1920×1200), Multi-touch, IPS, 400nits, Anti-glare, 16:10, 1000:1, 45% NTSC, 60Hz

Display / Touchscreen

On-cell multi-touch, supports 10-point touch
Non-touch

Input Device / Keyboard

6-row, spill-resistant, multimedia Fn keys, Copilot key

Input Device / Keyboard Backlight

LED backlight

Input Device / UltraNav

TrackPoint® pointing device, double-tap to open the TrackPoint® Quick Menu
Glass-like Mylar® surface multi-touch touchpad, 61 x 115 mm

Mechanical / Dimensions

315.9 x 223.7 x 17.7 mm

Mechanical / Weight

Models with black cover and 39.3Wh battery, Starting at 1.31 kg
Models with grey cover and 52.5Wh battery, Starting at 1.43 kg

Mechanical / Case Colour

Black
Grey

Mechanical / Case Material

Models with black cover: PC + 20% CF (top), PC + 20% CF (bottom)
Models with grey cover: aluminium (top), PC + 20% CF (bottom)

Network / Ethernet

Gigabit Ethernet, Realtek RTL8111EPV, 1x RJ-45, supports Wake-on-LAN

Network / WLAN + Bluetooth

Qualcomm® Wi-Fi 6E NFA725A, 802.11ax 2×2 Wi-Fi + Bluetooth 5.3

Network / WWAN

No support

Network / SIM Card

No physical SIM card inbox

Network / NFC

No support

Ports / Standard Ports

1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 2.1
1x HDMI® 2.1, up to 4K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)

Docking / Docking

Various docking solutions supported via Thunderbolt / USB-C

Security / Security Chip

Discrete TPM 2.0 (TCG certified, FIPS 140-2 certified) and Microsoft® Pluton TPM 2.0, one enabled at one time

Security / Physical Logs

Kensington® Nano Security Slot™, 2.5 x 6 mm

Security / Smart Card Reader

No smart card reader

Security / Fingerprint Reader

Touch style fingerprint reader integrated in power button, match-on-chip

Security / BIOS Security

NVMe® password
Power-on password
Supervisor password
System management password
Certificate based BIOS authentication
FIDO (Fast Identity Online) authentication
Self-healing BIOS

Security / Other Security

Camera privacy shutter (camera models)

Manageability / Systems Management

DASH

Warranty / Base Warranty

1-year courier or carry-in service
3-year (1-yr battery) courier or carry-in service
