Lenovo ThinkSystem SR250 V3 Rack Server

Call 519-483-3560 for pricing and specific model information

  • Intel® Xeon® E-2400 processor up to 8 cores at 95W
  • Up to 128GB TruDDR5 memory at 4400MHz ECC
  • Storage flexibility support for M.2, simple-swap NVMe (Gen4), 4x 3.5″ simple-swap/hot-swap or 10x 2.5″ HDDs/SSDs
  • Supports optional NVIDIA T1000 or T400 GPU
  • Supports a 300W fixed PSU or Dual Redundant power supplies
  • Lenovo XClarity support for simple enterprise-wide management
Categories: ,

Features

Optimized for Remote Installations

The Lenovo ThinkSystem SR250 V3 powered by the next-generation Intel® Xeon® E-2400 processors provide higher workload performance at an entry-level price point. Designed to the same standards as all ThinkSystem servers, the SR250 V3 brings high-reliability and security to any IT infrastructure.

The SR250 V3 also offers the latest DDR5 memory, PCIe 5.0, and GPU support for modern workloads like extending AI inferencing to remote installations, virtualization, and business applications.

Agile and Easy to Manage

The ThinkSystem SR250 V3 provides flexible storage options with multiple types ranging from mid-sized to large capacity. They also have hot-swap and simple swap options depending on your needs. The SR250 V3 have up to 2x PCIe slots to help tailor configurations to meet your needs.

The SR250 V3 includes the Lenovo XClarity Controller, that standardizes and automates server management tasks. It shares common options with the ThinkSystem portfolio enabling easier management across the entire IT infrastructure. XClarity also helps speed deployment.

High Value per Performance

The SR250 V3 has the price per performance ideal for growing businesses. It brings high value to your IT infrastructure with the Intel® Xeon® E-2400 and support for the latest technology like DDR5 memory and PCIe Gen5 which provides the speed and performance necessary to support virtualization and business applications.

Adding to the value performance, the SR250 V3 supports up to 8 core performance with no more than 95W CPUs, making it powerful, yet energy efficient. This is very important for clients who are running edge applications in a non-traditional data center setting.

Form Factor

1U rack-mount
Processor

Intel Xeon E-2400
Intel Pentium G7400
Intel Pentium G7400T
Chipset

Intel Raptor Lake PCH-S C266
Memory

Four DIMM sockets supporting Lenovo TruDDR5 DIMM. Support ECC UDIMMs
Memory / Maximum

Up to 128 GB using 4x 32 GB UDIMMs
Memory / Protection

Error-correcting code (ECC)
Disk Drive Bays

10 x 2.5" hot-swap SAS/SATA drive bays
8 x 2.5" hot swap SATA only, or SAS/SATA drive bays
4 x 3.5" hot-swap SATA only, or SAS/SATA drive bays
4 x 3.5" simple-swap drive bays, all SATA
4 x 3.5" simple-swap drive bays, 2x SATA and 2x NVMe
Maximum Internal Storage

2.5" drive bays:
78.TB using 10 x 7.68TB SATA 6Gb HS SSDs
24TB using 10 x 2.4TB 10K 2.5" SAS HDDs
3.5" drive bays
88TB using 4x 22TB 3.5" SAS HDDs
30.7TB using 4 x 7.68TB 3.5" SATA SSDs
Optical Drive Bays

No support
Tape Drive Bays

No support
Network Interfaces

Two integrated Gigabit Ethernet 1000BASE-T ports (RJ-45) based on Broadcom BCM5720 embedded controller, one can be shared with XCC for systems management. Third dedicated Gigabit Ethernet port for XCC systems management.
PCI Expansion Slots

wo PCIe slots depending on the riser selected:

Riser with two x8 slots:
Slot 1: PCIe G4 x8 (x8 slot, open-ended) 25W, half-length, low-profile
Slot 2: PCIe G4 x8 (x16 slot, closed-ended) 50W, half-length, low-profile
Slimline x8 connector (internal): PCIe G3 x4 (x8 slot, closed-ended) 25W, half-length, low-profile
Riser with one x16 slot:
Slot 1: Not connected
Slot 2: PCIe G5 x16 (x16 slot, closed-ended) 75W, half-length, half-height to support PCIe x16 card, such as GPU
Slimline x8 connector (internal): PCIe G3 x4 (x8 slot, closed-ended) 25W, half-length, low-profile
Ports

Front:
One USB 3.2 G1 (5 Gb/s) port
One USB 2.0 port (also for XClarity Mobile connectivity for local systems management)
Optional VGA port
Rear:
Two USB 3.2 G1 (5 Gb/s) ports
One VGA video
One RJ-45 systems management network port
Two RJ-45 GbE network ports
One serial port
Cooling

Four non-hot-swap system fans
Power Supply

One fixed 300W power supply, 80 PLUS Gold certified
Two hot-swap 800W redundant power supplies, 80 PLUS Platinum or Titanium certified, Energy Star and ErP Lot 9 compliant (Energy Star and ErP Lot 9 only with Intel Xeon processors)
Hot-swap parts

Hard drives and hot-swap power supplies
Systems Management

Operator panel with status LEDs. XClarity Controller 2 (XCC2) embedded management, XClarity Administrator centralized infrastructure delivery, XClarity Integrator plugins, and XClarity Energy Manager centralized server power management. Optional XCC2 platinum to enable premium functions.
Security features

Power-on password, administrator's password, Trusted Platform Module, supporting TPM 2.0. Optional lockable front bezel for physical security.
Video

G200 graphics with 16 MB memory, integrated into the XCC2. For use with local Administrator functions (not designed for workstation use). Maximum resolution is 1920×1200 32bpp at 60Hz.
Operating Systems Suported

Microsoft Windows Server
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
VMware ESXi
Limited Warranty

Three-year or one-year (model dependent) customer-replaceable unit and onsite limited warranty with 9×5 next business day (NBD).
Dimensions (WxDxH)

434.4 x 561 x 43 mm
Weight

Maximum configuration: 12.3 kg
