Forward-facing Lenovo ThinkCentre M90a Gen 5 (24" Intel) all-in-one PC, showing display & Full Function Monitor Stand

Lenovo ThinkCentre M90a Gen 5 (24″ Intel) All-In-One

Call 519-483-3560 for pricing and specific model information

  • Up to 14th Gen Intel® Core™ i7-14700
  • Up to Windows® 11 Pro
  • Up to NVIDIA® GeForce MX570A
  • Up to 64GB DDR5-5200
  • Up to two drives, 2x M.2 SSD
  • Up to 23.8″ FHD (1920×1080) IPS display, Anti-glare, 16:9, 250nits, 99% sRGB, hardware low blue light, flicker free, eyesafe 2.0
Categories: , Brand:

Features

Designed to brighten up any workspace

With its sleek design, the Lenovo ThinkCentre M90a Gen 5 all-in-one is a PC powerhouse. It runs on up to the Intel vPro® platform with 14th Gen Intel® Core™ processing muscle and boasts a stunning FHD display, with or without touchscreen. Plus, optional discrete graphics are ideal for video-editing or design work. Mounted on a choice of stands, including one that’s full function with adjustable tilt, lift, pivot, and swivel. And there’s even a docking space for your phone and keyboard to keep your workspace clutter-free.

Forward-facing Lenovo ThinkCentre M90a Gen 5 (24″ Intel) all-in-one PC

A smarter way to work, by far

Thanks to our Intelligent Cooling Engine (ICE) 6.0, the ThinkCentre M90a Gen 5 all-in-one offers various power modes to meet your various computing needs. Choose a 15% power boost experience, a super quiet mode that cuts system noise by up to three decibels, or opt for maximum cooling.

Protecting your data, ideas, & more

Experience unparalleled peace of mind with ThinkShield, comprehensive security that comes with every ThinkCentre. The ThinkCentre M90a Gen 5 all-in-one PC leverages up to Intel vPro® for robust, hardware-enhanced device protection. Additional security measures include BIOS-based Smart USB Protection, and a physical shutter you can use to open and close the webcam, further safeguarding your privacy.

Close up of the Lenovo ThinkCentre M90a Gen 5 (24″ Intel) all-in-one PCs webcam shutter, showing the on/off buttons for camera & mic
Nurse sat a desk looking at Lenovo ThinkCentre M90a Gen 5 (24″ Intel) all-in-one PC, with patient in wheelchair & another nurse in the background.

Because things happen

In addition to our stringent internal testing, the ThinkCentre M90a Gen 5 all-in-one PC has been evaluated against US Department of Defense’s MIL-STD 810H standards and undergone more than 200 quality checks to confirm its ability to withstand extreme scenarios. These tests encompass a wide range of challenging factors, from the icy expanses of the Arctic tundra to dust-laden desert winds, including assessments for temperature, pressure, humidity, vibration, and beyond.

Built with the planet in mind

By 2025, Lenovo is committed to obtaining 90% of our global operations electricity from renewable sources, removing one-million tons of greenhouse gas emissions from our supply chain. It’s why this all-in-one PC, for instance, meets global standards for energy-efficiency and health & safety. And why it comes with 90% sustainable packaging and comprises recycled materials.

Side view of Lenovo ThinkCentre M90a Gen 5 (24″ Intel) all-in-one PC on a desk, next to a keyboard & mouse, with display showing images of a skydiver

Ports & Slots

Left, right, & rear views of Lenovo ThinkCentre M90a Gen 5 (24″ Intel) all-in-one PC, showing left-, right-, & rear-side ports
  • 1. Optional: Optical disk drive (ODD)
  • 2. USB-A (USB 5Gbps, supports USB power on)
  • 3. USB-A (USB 5Gbps)
  • 4. USB-A (USB 5Gbps)
  • 5. USB-C® (USB 10Gbps) Supports 15W charging
  • 6. Ethernet (RJ-45)
  • 7. HDMI in 1.4 / out 2.1 combo (up to HDMI 2.1 TDMS)
  • 8. DisplayPort 1.4 (out)
  • 9. Optional: Serial port
  • 10. Power Connector
  • 11. Microphone mute button
  • 12. PC / monitor mode switch
  • 13. USB-A (USB 10Gbps)
  • 14. USB A (USB 10Gbps)
  • 15. USB A (USB 10Gbps)
  • 16. Headphone / mic combo
  • 17. Optional: 3-in-1 card reader
  • 18. Power button
Processor / Processor Family

13th / 14th Generation Intel® Core i3 / i5 / i7 Processor
Processor / Processor

Core i3-14100 / 4 (4 P-core + 0 E-core) / 8 Threads / P-core 3.5GHz / P-core 4.7GHz / 12MB / Intel® UHD Graphics 730, Core i5-13500 / 14 (6 P-core + 8-E-core) / 20 Threads / P-core 2.5GHz / E-core 1.8GHz / P-core 4.8 GHz / E-core 3.5GHz / 24MB Cache / Intel UHD Graphics 770, Core i5-14500 / 14 (6 P-core + 8 E-core) / 20 Threads / P-core 2.6GHz / E-core 1.9GHz / P-core 5.0GHz / E-core 3.7GHz / 24MB Cache / Intel® UHD Graphics 770, Core i7-14700 / 20 (8 P-core + 12 E-core) / 28 Threads / P-core 2.1GHz / E-core 1.5GHz / Max Turbo up to 5.4GHz / P-core 5.3GHz / E-core 4.2GHz / 33MB Cache / Intel® UHD Graphics 770
Operating System / Operating System

Windows 11 Pro
Graphics / Graphics

Intel® UHD graphics 730, Integrated, Shared, 4096×2160@60Hz(HDMI®) / 4096×2160@60Hz(DP), 1x HDMI® 2.1 TMDS / 1x DP 1.4, DirectX® 12, Intel® UHD graphics 770, Integrated, Shared, 4096×2160@60Hz(HDMI®) / 4096×2160@60Hz(DP), 1x HDMI® 2.1 TMDS / 1x DP 1.4, DirectX® 12, NVIDIA® GeForce MX570A, Discrete, 4GB GDDR6, 4096×2160@60Hz(HDMI®) / 4096×2160@60Hz(DP), 1x HDMI® 2.1 TMDS / 1x DP 1.4, DirectX® 12
Monitor / Monitor Support

Supports up to 3 independent displays via native display and 2 external monitor; supports external monitors via DisplayPort™ and HDMI®; work as standalone monitor via HDMI® (HDMI® in / out combo)
Chipset / Chipset

Intel® Q670 chipset
Memory / Max Memory

Models with Core i3/i5: Up to 64GB DDR5-4800, Models with Core i7: Up to 64GB DDR5-5200
Memory / Memory Slots

Two DDR5 SO-DIMM slots, dual-channel capable
Memory / Memory Type

DDR5-4800, DDR5-5600
Memory / Memory Protection

Non-ECC
Storage / Storage Support

Models with Intel® UHD graphics: Up to two drives: 2x M.2 SSD, M.2 SSD up to 2TB each, Models with NVIDIA® GeForce MX570A: Up to one drives: 1x M.2 SSD, M.2 SSD up to 2TB each
Storage / Storage Type

M.2 2280 SSD, PCIe® NVMe® / PCIe® 4.0 x4, Opal 2.0
Storage / RAID

RAID 0/1 support for SSDs
No Support
Removable Storage / Optical

DVD burner (DVD±RW), SATA connector, slim (9.0mm)
Removable Storage / Card Reader

No card reader
Multimedia / Audio Chip

High Definition (HD) Audio, Realtek® ALC233NL-VB2-CG codec
Multimedia / Speakers

Stereo speakers, 3W x2, Dolby Atmos®
Multimedia / Microphone

Dual-microphone array
Multimedia / Camera

5.0-megapixel, IR + RGB hybrid, with ThinkShutter (physical switch on/off), ±20° view angle adjustable, Windows® Hello support
Power Supply / Power Supply

180W, Fixed, 90% Efficiency, 100V – 240V, 50-60Hz, 230W, Fixed 92% Efficiency, 100V – 240V, 50-60Hz
Display / Display

23.8", FHD (1920×1080), Multi-touch, IPS, 250nits, Anti-glare, 16:9, 1000:1, 72% NTSC, 60Hz, 14ms response Time, 23.8", FHD (1920×1080), None, IPS, 250nits, Anti-glare, 16:9, 1300:1, 99% sRGB, 60Hz, 14ms response Time
Display / Touchscreen

Advanced In-cell Touch (AIT), supports 10-point touch, None
Input Device / Keyboard

Lenovo® Calliope Keyboard (USB connector), black
Input Device / Mouse

Lenovo® Calliope Mouse (USB connector), black
Mechanical / Buttons

Microphone mute button, Monitor / PC mode switch button, Power button
Mechanical / Form Factor

AIO (23.8 inches)
Mechanical / Dimensions (WxDxH)

Lowest in flat mode: 539.6 x 344.19 x 227.54 mm (21.24 x 13.55 x 8.96 inches) Highest in vertical mode: 539.6 x 252.60 x 472.00 mm (21.24 x 9.94 x 18.58 inches)
Mechanical / Packaging Dimensions (WxDxH)

Models (with UltraFlex V stand): 690 x 545 x 238 mm (27.17 x 21.46 x 9.37 inches)
Mechanical / Weight

Models (with UltraFlex V stand), Around 7.83 kg (17.3 lbs)
Mechanical / Case Colour

Black
Mechanical / Bays

1x slim ODD bay
Mechanical / Expansion Slots

Models with Intel® UHD graphics: Three M.2 slots (one for WLAN, two for SSD), Models with NVIDIA® GeForce MX570A: Two M.2 slots (one for WLAN, one for SSD)
Mechanical / EOU

Toolless cover, stand, motherboard shielding, and memory assembly / removal
Mechanical / Stand

UltraFlex V stand, supports -5° to +70° tilt, up to 70°±2° lift (up to 179.96mm lift in flat mode / up to 84.37mm lift in vertical mode)
Mechanical / Mounting

Supports VESA mount 100mm
Network / Ethernet

Gigabit Ethernet, Intel® Ethernet Connection I219-LM, 1x RJ-45, supports Wake-on-LAN
Network / WLAN + Bluetooth

Intel® Wi-Fi® 6E AX211, 802.11ax 2×2 Wi-Fi® + Bluetooth® 5.3, Intel® vPro® technology support, M.2 Card
Ports / Rear Ports

1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with data transfer and 15W charging, 3x USB-A (USB 5Gbps / USB 3.2 Gen 1), 1x HDMI® (HDMI® in 1.4 / HDMI® out 2.1 TMDS combo port), 1x DisplayPort™ 1.4, 1x Ethernet (RJ-45)
Ports / Right Ports

3x USB-A (USB 10Gbps / USB 3.2 Gen 2), 1x headphone / microphone combo jack (3.5mm)
Security / Security Chip

Discrete TPM 2.0, TCG certified, FIPS 140-2 certified
Security / Physical Locks

Kensington® Security Slot, 3 x 7 mm
Security / Other Security

(Optional) Smart Human Presence Detection (Camera with Radar Sensor), ThinkShutter camera cover (camera models)
Security / BIOS Security

Administrator password, Boot sequence control, Boot without keyboard and mouse, Hard disk password, Individual USB port disablement, Power-on password, Self-healing BIOS, Smart USB protection (allows keyboard / mouse only, blocks all storage devices)
System Management / System Management

Intel® vPro® Enterprise, Non-vPro®
Warranty / Base Warranty

3-year limited onsite service
